Brother BAS-311F-0 - Creating a Circle (Zigzag Circle) by Specifying 3 Points

Programmer 165
Chapter 3 Programming with Command Function
Creating a circle (zigzag circle) by specifying 3 points
Command to be used
Input the overlap stitch counts in Values 0 - 9 are available for input.
Input this command to create a zigzag circle. Input the zigzag width in .
The zigzag width can be specified from 1.0 - 25.5 mm.
To specify the width of 10.0 mm or more, input
and input the
width in 3 digits, then press
.
Example: Pitch Input
3.5mm
18.0mm
Input this command to create a zigzag circle. Input the zigzag stitch length in
.
Example: Pitch Input
0.5mm 005
12.0mm 120
1. Select the sewing start position with and press .
2. Input .
3. Input the stitch length in 3 digits and press .
