Programmer 133
Chapter 3 Programming with Command Function
Inputting the end code
1. Press at the last stitch and press
.
The needle moves to points G and H.
Saving
1. Specify the program number on the operation
panel and press the read/write switch for writing
into the floppy disk.
Ending program
1. Press .
Feed
After thread breaking, a feed is set for continuous sewing with
the work clamp in position.
The example in the left is used for explanation of
programming pattern 2 with a feed after pattern 1.
Programming
1. Press .
The work clamp moves to the home position and
the programmer screen is displayed.
2. Move the work clamp with . Press
when the needle point is at point A of the
pattern.
The first stitch (point A) is programmed.
To Next Page
