134 Programmer
Chapter 3 Programming with Command Function
3. Program pattern 1.
4. Input point B and press
.
5. Move the work clamp with
. Press
when the needle point is at point C of the
pattern.
6. Program pattern 2.
Inputting the end code
1. Press at the last stitch and press
.
The work clamp returns to the start position.
Saving
1. Specify the program number on the operation
panel and press the read/write switch for writing
into the floppy disk.
Ending program
1. Press .
To Next Page
