Brother BAS-311F-0 User Manual

Programmer 15
Chapter 1 Preparations of operation
Notes for programming
Pattern sheet
Use thin plotting paper or prepare copies of pattern sheet.
The pattern sheet is designed in the original scale. Adjust the size to magnification (2, 5, or
10) for magnified input.
Stitch length
BAS-300 Series 0.3-12.7 mm
KE-436B, 436C 0.3-10.0 mm
Stitch count
Maximum available count is 20,000.
Available types of floppy disk
Data type (*1) Stitch count for memory Data resolution Disk Format Write
BAS-300E Data
(BAS-300F
KE-436B, 436C)
20,000 stitches/ pattern
100 patterns
Total: Up to 360,000 stitches
0.05 mm/pulse
(*4)
Available
TFD embroidery data
(*2) (DST, DSB, DSZ)
50,000 stitches/pattern 0.1 mm/pulse
2HD DOS/V 1.44M
Not
available
Formar BAS-300A
data
4,000 stitches/pattern
10 patterns
Total: Up to 40,000 stitches
0.1 mm/pulse Available
Formar BAS-300 data
2,000 stitches/pattern
10 patterns
Total: Up to 20,000 stitches
0.2 mm/pulse
2DD (*3)
Formatted
automatically.
Not
available
(*1) As shown in the table, four types of data are available for writing. Data written into 2HD and
2DD disks are automatically converted to BAS-300E and former BAS-300A data respectively.
(*2) TFD data is converted to BAS-300E data by the programmer and becomes available for sewing.
(*3) Restrictions for 2DD floppy disks.
The use of following functions added to the E series are restricted to maintain the compatibility
with former BAS-300A data.
(*4) The machine resolution limit for KE-436B and 436C are 0.1mm/pulse.
Restricted functions A Series (2DD) E, F Series (2HD) KE Series (2HD) Commands
Resolution 0.1mm/pulse 0.05mm/pulse 0.1 mm/pulse
Low-speed sewing
2 options:
400 and 1200 rpm
4 options:
400, 600, 800, 1200
rpm
4 options:
400, 600, 800, 1200
rpm
Split function in
sewing
No Yes Yes
Stoppage of split
with the needle at
the lower end
No Yes Yes
Extended option
output
No Yes No
