188 Programmer
Chapter 3 Programming with Command Function
5. Input the magnification in 3 digits in the Y direction and press .
Magnification values of 0 - 400 are available for input.
6. Input the stitch length in 3 digits and press .
If the value is "000", the stitch count remains unchanged. The stitch length increases or decreases.
Repeated copying
Command to be used
Copying data from the sewing start position or the feed point (excluding the
number of feed boundaries to be ignored) to the current needle position for
the area after the current needle position
1. Move the needle to the desired position.
Refer to “Moving needle point” (page 123).
2. Input .
The needle follows the copied data. Press to cancel halfway.
To Next Page
