Programmer 35
Chapter 2 Programming with Help Function
7. Move the work clamp with . Press
twice when the needle point is at point B of
the pattern.
8. Program points C, D and E.
9. When point E is programmed, press
again.
10. Program point F.
11. When point F is programmed, press
again.
12. Press
.
The needle moves to points F, G and H.
13. When the needle stops, press three times.
Inputting the end code
1. Select with and press .
2. Select the end code type with
and press
.
"111" is selected in the example. Press and the
work clamp returns to the first stitch (point A).
3. Press .
The work clamp returns to the home position.
