Programmer 137
Chapter 3 Programming with Command Function
Programming
1. Press .
The work clamp moves to the home position and
the programmer screen is displayed.
2. Move the work clamp with . Press
when the needle point is at point A of the
pattern.
The first stitch (point A) is programmed.
3. Create the program to point B.
4. Input point B and press
.
Input the command symmetric to Y axis.
5. The needle point moves slowly from point B to
point A in the right half and it is automatically
programmed. Press
to make fast
movement.
Inputting the end code
1. Press when needle stops at point
A.
The work clamp returns to the start position.
Saving
1. Specify the program number on the operation
panel and press the read/write switch for writing
into the floppy disk.
Ending program
1. Press .
