Brother MFC-9330CDW Service Manual

2-16
Confidential
4800 After the waste toner sensor
detected that the waste toner
box was almost full, pages more
than the specified number have
been printed.
2-44
4900 ---
4A00 ---
4B01 Dot counter of the toner cartridge
(Black) or develop roller counter
reaches the upper limit soon.
2-45
4B02 Dot counter of the toner cartridge
(Yellow) or develop roller counter
reaches the upper limit soon.
2-45
4B03 Dot counter of the toner cartridge
(Magenta) or develop roller
counter reaches the upper limit
soon.
2-45
4B04 Dot counter of the toner cartridge
(Cyan) or develop roller counter
reaches the upper limit soon.
2-45
4C01 Dot counter of the toner
cartridge (Black) or develop
roller counter has reached the
upper limit was detected.
2-46
4C02 Dot counter of the toner
cartridge (Yellow) or develop
roller counter has reached the
upper limit was detected.
2-46
4C03 Dot counter of the toner
cartridge (Magenta) or develop
roller counter has reached the
upper limit was detected.
2-46
4C04 Dot counter of the toner
cartridge (Cyan) or develop roller
counter has reached the upper
limit was detected.
2-46
4C05 During printing, dot counter of
color toner cartridge or develop
roller counter has reached the
upper limit was detected.
2-46
Error
codes
Problem
Refer
to:
4D01 ---
4E01 ---
4F01 The new toner sensor of the
toner cartridge (Black) could not
detect a new cartridge properly.
2-47
4F02 The new toner sensor of the
toner cartridge (Yellow) could not
detect a new cartridge properly.
2-47
4F03 The new toner sensor of the
toner cartridge (Magenta) could
not detect a new cartridge
properly.
2-47
4F04 The new toner sensor of the
toner cartridge (Cyan) could not
detect a new cartridge properly.
2-47
5001 ---
5002 Printable pages set for the PF kit
1 has reached the upper limit.
2-47
5003 ---
5004 ---
5005 ---
5100 ---
5200 ---
5301 ---
5302 ---
5401 ---
5402 ---
5406 ---
5502 ---
5602 ---
5702 ---
5801 ---
5802 ---
5902 ---
Error
codes
Problem
Refer
to:

Brother MFC-9330CDW Specifications

Print Specifications

print speed black	up to 23 ppm
print speed color	up to 23 ppm
print resolution	up to 600 x 2400 dpi

Copy Specifications

copy speed black	up to 23 cpm
copy speed color	up to 23 cpm
copy resolution	600 x 600 dpi

Scan Specifications

scan resolution optical	1200 x 2400 dpi
scan resolution interpolated	19200 x 19200 dpi
document glass size	8.5” x 11.7”

Fax Specifications

fax modem speed	33.6k bps
fax page memory	up to 500 pages
speed dial locations	200

Paper Handling

auto document feeder capacity	up to 35 pages
paper size maximum	up to 8.5” x 14” (legal)
standard paper capacity	250 sheets

Power and Energy

deep sleep mode power consumption	<2W
automatic duplex printing	Yes
energy star qualified	Yes
