Brother PE-Design Next User Manual

150
Tutorial 8: Manual Punching
After clicking point 4 (the last point of the
running-type pattern), click , and then click
in the Design Page to specify point 5 through
7.
 The area surrounded by the line is
specified as a block.
Click in the Design Page to specify points 8
through 15.
 The blocks A through E will be created, in
order.
Click in the Design Page to specify points 16
through 40.
Click point 41 (the last point of the pattern),
and then press the key to complete
the pattern.
b Memo:
To remove the last point that was entered,
press the key, or click the right
mouse button.
BackSpace
6
5
7
6
7
15
A
13
11
9
8
10
12
14
B
C
E
D
b Memo:
• The pattern can also be completed by
double-clicking point 41.
• Points entered with the Manual Punch tools
can be edited with the Point Edit tool.
c
“Selecting points” on page 62.
8
17
19
21
23
25
27
29
31
33
35
37
39
38
36
34
32
30
28
26
24
22
20
18
16
40
9
Enter
41
