L-TRX/L-19F
H172203_1_001 111 / 234
Service Functions
Most information on this page are for service use only.
Figure11.12: Service Functions
1 FPGA revision and build date (yymmdd).
2 Hardware code = used by ELCB to identify Lock system.
3 Firmware status and file name (download and factory default).
4 Reboot buttons: use ‚Factory Default FW‘ to revert to factory firmware.
5 Mode register status.
6 L-TRX status information.
