Operation 55
“MOTORS ENABLED” light
This light indicates when the servo motors have power,
and should turn on when the “RUN” button is pushed
and stays on until the “STOP” button is pushed or the
front cover is opened.
“INITIALIZED” light
This light will be “OFF” when the Servo Tyer is first powered
up. It will turn “ON” and stay “ON” when homing sequence
has been successfully completed. This light must be "ON”
before the Servo Tyer can be threaded.
“TYER FAULT” light
This light will indicate problems with the Servo Tyer.
During normal operation, the light should be off. The
light will turn on for any reason if the Servo Tyer drops
out of the run mode. For example, if the “STOP” button
is pushed, the front cover is opened, a ribbon drop is
detected (the fault light will also turn on, but the Servo
Tyer will stay in the run mode). This light toggles on
and off whenever the audible alarm is beeping and
assists the operator in identify which machine is
currently registering an alarm.
