 Fuse And Circuit Breaker List
There are fourteen (14) fuses and circuit breakers in the Main Enclosure. Four (4) fuses
reside on the Aux. board, six (5) are mounted on a DIN rail below the disconnect, and
four (4) are located on the Field Termination Board.
MAIN PANEL
SYMBOL
PART #
TYPE
DESCRIPTION
FU1
C06543
10 AMP (
fuse
)
MAIN POWER
FU2
C06543
10 AMP (
fuse
)
MAIN POWER
FU3 C07062 20 AMP (fuse) TRANSFORMER SECONDARY
CB3 C07649-006
6 AMP (CIRCUIT
BREAKER)
BRUSH MOTOR
CB4 C07649-002
6 AMP (CIRCUIT
BREAKER)
BLOWER (IF EQUIPPED)
AUXILIARY BOARD FUSE
S
SYMBOL
PART #
TYPE
DESCRIPTION
PC2 FU1
C07036
10 AMP, MDA
NEEDLE MOTOR OUTPUT
PC2 FU2 C07036 10 AMP, MDA
TWISTER HOOK MOTOR
OUTPUT
PC2 FU3 C01268 5 AMP, MDA
HOLDER SHEAR MOTOR
OUTPUT
PC2 FU4 C01268 5 AMP, MDA
GATHERING BELT MOTOR
OUTPUT
FIELD TERMINATION BO
ARD FUSES
SYMBOL
PART #
TYPE
DESCRIPTION
PC1 FU1
C06585
3 AMP, GLD
HORN RELAY
PC1 FU2
C06585
3 AMP, GLD
BAGGER ENABLE CIRCUI
T
PC1 FU3 C06585 3 AMP, GLD
SERVO ENABLE (DC
CONTACTOR)
PC1 FU4
C06585
3 AMP, GLD
COUNTER RELAY
CAUTION: Be careful when removing fuses from any of the circuit
boards. Never use a metal screwdriver to pry out the fuses because
this damages the traces on the board below the fuse holders.
