Ribbon Tension Assembly
30200404 Rev E RH
30200504 Rev E LH
FOLD OUT TO VIEW DRAWING
9 10
ITEM # QTY. PART# DESCRIPTION
1 1 100578 BUSH,BRZ,FLG,3/8ID 1/2OD X3/8L
2 1 103519 SPRING EXTENSION
3 4 104239 CLAMP RIBBON FEED BELT
4 1 112643 SERIAL PLATE
5 2 122222 BUSHING, 1/2 X 3/4 X .074 MACH.
6 6 122232 BUSHING 1/2 X 3/4 X .010 MACH
7 1 152076 BEARING, 1/2” CAM FOLLOWER
8 6 152148 MOLDED RECESS BUMPER
9 1 152151 COLLAR,3/8” SET,ZINC PLATED
10 1 174248 MOUNT, CABLE
11 2 302021 BUSHING, MACH, ¼ X ½ X .010
12 2 302022 BUSHING, MACH, 1/4 X 1/2 X .005
13 1 302161 SPRING RIBBON TENSION
14 2 302162 ROD, BELT CLAMP BRAKE
15 2 302163 BLOCK, BELT CLAMP
16 2 302164 SHAFT, RIBBON TENSION
17 1 302166 ASSY, RIBBON ROLLER
18 1 302168 SHAFT, RIBBON TENSION
19 1 302169 SHAFT, 2ND ROLLER
20 1 302170 SPACER, SENSOR ROLLER
21 RH 2 302171 NUT, RIBBON TENSION, R.H.
21 LH 2 302190 NUT, RIBBON TENSION, L.H.
22 2 302174 PLATE, OUTER SPOOL
23 2 302178 RETAINER, RIBBON SPOOL
24 1 302179 PLATE, CONTROL BOX
25 REF. 302180 STANDOFF, CONTROL BOX
26 REF. 302182 NAMEPLATE,OPERATOR BOX,2000/2100
27 REF. 302185 ENCLOSURE,REWORK,2000 (A08369)
28 RH 2 302192 NAMEPLATE, RIBBON SPOOL, 2000
28 LH 2 302183 NAMEPLATE, RIBBON SPOOL, 2100
29 1 302243 SLEEVE, BRAKE ARM, RIBBON TENSION
30 1 302244 ARM, BRAKE RIBBON TENSION, SERVO
31 RH 1 302248 A/W, MOUNT, R.H.
31 LH 1 302249 A/W, MOUNT, L.H.
32 1 302252 SPRING ADJUSTER
33 RH 2 302370 ASSY, INNER SPOOL, R.H.
33 LH 2 302371 ASSY, INNER SPOOL, L.H.
34 RH 1 302372 ASSY, DANCER ARM, R.H.
ITEM # QTY. PART# DESCRIPTION
34 LH 2 302373 ASSY, DANCER ARM, L.H.
35 1 302472 SPACER, DOUBLE SPOOL
36 1 302479 BUMPER, RIBBON TENSION ARM
37 1 302874 Lee Spring LE-031 D8
38 1 305111 ACTUATOR, 2ND RIBBON TENSION
39 1 305112 ARM, PIVOT 2ND R.T.
40 1 305113 WASHER, DELRIN RT ARM
41 1 305115 PLATE FULL DOUBLE RIBBON
42 2 504521 BELT, V 1/2 X 15”
43 1 955405 NUT HEX JAM 3/8-16 UNC SST
44 1 955407 NUT HEX JAM 5/16-18 UNC SST
45 1 955621 NUT HEX NYLOC #10-24 UNC SST
46 2 955661 NUT HEX NYLOC 1/4-20 UNC SST
47 1 955822 NUT HEX MACH. #10-32 UNF SST
48 2 955823 NUT HEX MACH #10-24 UNC SST
49 1 955938 WASHER, LOCK 3/8” SST
50 8 955939 WASHER, LOCK 5/16” SST
51 2 955940 WASHER LOCK 1/4” SST
52 4 955941 WASHER LOCK #10 SST
53 4 955977 WASHER FLAT 1/4” SST
54 1 962508 SCREW THUMB 1/4-20 UNC X 1/2 SST
55 4 971206 SCREW SET SOC 1/4-20 UNC X 3/8 SST
56 5 974910 SCREW SHLDR 1/4 X 5/8, #10-24 SST
57 1 975108 SCREW SHLDR 3/8 X 1/2, 5/16-18 SST
58 1 975220 SCREW SHLDR 1/2 X 1 1/4, 3/8-16 SST
59 3 978906 SCREW SOC HD CAP #10-24 UNC X 3/8 SST
60 3 981712 SCREW FLT HD SOC 1/4-20 X 3/4 SST
61 6 982308 SCREW FLT HD SOC #10-24 X 1/2 SST
62 2 982906 SCREW FLT HD SOC #8-32 X 3/8 SST
63 6 986906 SCREW BUTT HD SOC #8-32 X 3/8 SST
64 2 987504 SCREW BUTT HD SOC #6-32 X 1/4 SST
65 8 989712 SCREW FIN HEX 5/16-18 X 3/4 SST
66 3 989928 SCREW FIN HEX 1/4-20 X 1 3/4 SST
67 2 A02359 RIBBON ROLLER
68 2 A02363 BUSHING, RIBBON ROLLER
69 2 C07625 SENSOR,PROX,8MM,10-30VDC,NPN,NO,QC
70 2 C07626 SENSOR,CABLE,M8,3WIRE,F,QC,90
