Troubleshooting 127
Flow Chart 0-12 E114 Error Code
E114
CONTROLLER IS NOT ABLE TO MOVE THE NEEDLE TO ITS STARTING POSITION
This error only occurs while the tyer is in its homing sequence. After all motors have found their home
proxes, the controller tries to move all motors to their starting positions. If the needle motor has not
reached its starting position after trying for 30 seconds, then this error is set.
SAFETY WARNING:
The following troubleshooting procedure may require that tests be made with the electrical
enclosures open and power turned “ON”. These tests should only be conducted by authorized
personnel who are aware of the electrical and mechanical hazards present.
Clear jam.
The most likely reason for this error is a mechanical obstruction or
jam which is preventing the needle from moving as needed. With
power turned “OFF”, turn the needle motor thru its complete range of
motion (MTR1) < 360°, check for debris, is a jam present?
Check for low voltage at the
motor power supply, if problem
persists replace Aux board.
Yes No
To Next Page
