Flow Chart 0-22 E134 Error Code
E134
CONTROLLER NOT ABLE TO MOVE THE SHEAR MOTOR TO ITS STARTING POSITION
This error only occurs while the tyer is in its homing sequence. After all motors have found their home
proxes, the controller tries to move all motors to their starting positions. If the shear motor has not
reached its starting position after trying for 30 seconds, then this error is set.
SAFETY WARNING:
The following troubleshooting procedure may require that tests be made with the electrical
enclosures open and power turned “ON”. These tests should only be conducted by authorized
personnel who are aware of the electrical and mechanical hazards present.
Clear jam.
The most likely reason for this error is a mechanical obstruction or jam which
is preventing the holder shear from moving as needed. With power turned
“OFF”, turn the holder shear motor thru its complete range of motion (MTR3)
≥ 360°, check for debris, is a jam present?
Check for low voltage at the
motor power supply, if problem
persists replace Aux board.
Yes No
To Next Page
