Chapter 7
Flow Chart 0-21 E132 Or E133 Error Code
E132-133
ONLY ONE EDGE OF HOLDER/SHEAR'S HOME PROX IS DETECTED
This error only occurs while the tyer is in its homing sequence. It indicates either of two similar conditions.
E132 indicates that the controller detected the shear's home prox turning “ON”, but it cannot drive the
shear cam past the prox to turn the prox “OFF”. E133 indicates that the controller detected the shear's
home prox turning “OFF”, but it cannot drive the shear cam back over the prox to turn the prox “ON”.
SAFETY WARNING:
The following troubleshooting procedure may require that tests be made with the electrical
enclosures open and power turned “ON”. These tests should only be conducted by authorized
personnel who are aware of the electrical and mechanical hazards present.
Clear jam.
The most likely reason for this error is a mechanical obstruction or jam which
is preventing the holder shear from moving as needed. With power turned
“OFF”, turn the holder shear motor thru its complete range of motion (MTR3)
≥ 360°, check for debris, is a jam present?
Initiate another homing sequence, does the motor move
in both directions while searching for home prox?
Does prox light turn
“ON” and “OFF” when
activated by hand?
Does prox LED on FTB turn
“ON” and “OFF” when
activated by hand?
Aux board bad,
replace Aux board.
Yes No
Aux board bad,
replace Aux board.
Check 12VDC and return wiring,
check FTB and prox cable
connections, fix as necessary.
Prox faulty, replace prox.
Yes No
Yes
Yes
Or
No
To Next Page
