30 Chapter 2
 Ribbon Guide
The Ribbon Guide is positioned so the downstream side of the lobe is flush with the
mounting block, with the belt pulley positioned so the upper belt is approximately 1/8”
from the needle shaft. It is used to increase or decrease the tie window.
Tie Window
Ribbon Guide
