Chapter 5
Spacing of Twister Hook Shaft to Tip Of Holder Shear
The proper spacing is 3/32 as shown below. If the twister hook shaft and the tip of the
holder shear are too close, the ribbon will sometimes wrap around the shaft of the hook.
The only adjustment available is the play in the mounting holes for the twister hook
bearing tower and the holder shear mounting.
Product Flow
The Holder / Shear must be on the inside position and the Twister
Hook notch facing away for proper measurement.
