Flow Chart 0-33 Tyer Aborts Cycle On Good Package
Tyer aborts tie cycle of apparently good package
SAFETY WARNING:
The following troubleshooting procedure may require that tests be made with the electrical enclosures
open and power turned “ON”. These tests should only be conducted by authorized personnel who are
aware of the electrical and mechanical hazards present.
Ribbon dispense
prox not properly
adjusted.
Ribbon dispense
prox not
working.
Ribbon has
jumped out of
the needle.
Ribbon has
jumped out of
ribbon roller
above needle.
Adjust prox closer to ribbon roller. Be sure that the prox can
detect all of the steel dowels in the roller.
Check wiring and power to prox. Replace if necessary. You
may disable the Package Recognition system with DIP switch
6 on the AUX board.
Open front cover and place ribbon into roller of needle.
Place ribbon properly into ribbon roller.
