FOLD OUT TO VIEW DRAWING
7 8
Tyer Covers
211142 Rev C RH
211143 Rev C LH
ITEM # QTY. PART# DESCRIPTION
1 1 103972 SENSOR,MICRO SWITCH
2 2 111174 DECAL, KEEP THIS GUARD IN PLACE
3 1 302043 PLATE, SMALL UPRIGHT
4 RH 1 302080 A/W, LOWER FRONT PLATE, RH
4 LH 1 302081 A/W, LOWER FRONT PLATE, LH
5 2 302180 STANDOFF, CONTROL BOX
6 RH 1 302196 TRIGGER ARM REWORK RH
6 LH 1 302203 TRIGGER ARM REWORK LH
7 RH 1 302280 MOUNT LOWER TUNNEL RH
7 LH 1 302281 MOUNT LOWER TUNNEL LH
8 RH 1 302284 GUIDE, INNER TOP, RH
8 LH 1 302285 GUIDE, INNER TOP, LH
9 RH 1 302323 A/W, GUARD SERVO, RH
9 LH 1 302324 A/W, GUARD SERVO, LH
10 1 302361 DECAL, SMALL, KEEP GUARD IN PLACE
11 RH 1 302388 MOUNT, CE MAGLOCK, RH
11 LH 1 302431 MOUNT, CE MAGLOCK, LH
12 1 302801-001 DECAL SMALL HAND DANGER
13 1 716191 A/W, MOUNT - TYER PIVOT T-BRUSH
14 RH 1 716450 A/W, INLET GUARD, 2000, TAPERED BRUSH
14 LH 1 716451 A/W, INLET GUARD, 2100, TAPERED BRUSH
15 2 955621 NUT HEX NYLOC #10-24 UNC SST
16 4 955941 WASHER LOCK #10 SST
17 2 955978 WASHER FLAT #10 SST
18 3 958510 PIN, ROLL 1/4” X 5/8”
19 4 978912 SCREW SOC HD CAP #10-24 UNC X 3/4 SST
20 1 C07219 SENSOR,INTERLOCK,MAGNETIC,KEYED
21 1 C07220 ACTUATOR, MAGNET
To Next Page
