Operator Display
210002-001/-002 Rev G
ITEM # QTY. PART# DESCRIPTION
1 4 174069 STANDOFF,#6-32 X 1/2,ALUM,HEX
2 1 210001 CABLE,ASSY,DISPLAY (VFD)
3 1 210204 ASSY,CABLE,PWR,DISPLAY-POWER SUPPLY
4 1 302449 BRACKET, DISPLAY
5 1 302450 WASHER, DISPLAY PIVOT
6 1 302758 BAR, DISPLAY STANDOFF
7 1 610000 DISPLAY, VFD (PRODUCTION)
8 1 610001 DISPLAY, FILTER (GREEN)
9 4 610004 STANDOFF, #4-40 UNC, .625 L.
10 1 610953 CONNECTOR, CORD, .20-.35, DOME, NYLON
11 1 610955 CONNECTOR,SEAL RING,1/2NPT,POLYETH
12 1 611566 PCBA, CONVERTER 12V TO 5V
13 1 710000 BRACKET, (VFD) DISPLAY BOX
14 1 710001 ENCLOSURE,REWORK,2000 (610002)VFD
15 1 710003 SPACER, HEAT SINK, MOUNT PCBA
16 4 710208 SPACER, 1/2OD X .257ID X .281L
17 1 955619 NUT HEX NYLOC 5/16-18 UNC SST
18 4 955621 NUT HEX NYLOC #10-24 UNC SST
19 1 955624 NUT HEX NYLOC #6-32 UNC SST
20 4 955661 NUT HEX NYLOC 1/4-20 UNC SST
21 8 955935 WASHER LOCK #4 SST
22 8 955936 WASHER LOCK #6 SST
23 4 955978 WASHER FLAT #10 SST
24 4 978908 SCREW SOC HD CAP #10-24 UNC X 1/2 SST
25 8 984804 SCREW BUTT HD SOC #4-40 X 1/4 SST
26 1 989712 SCREW FIN HEX 5/16-18 X 3/4 SST
27 4 989920 SCREW FIN HEX 1/4-20 X 1 1/4 SST
28 8 999504 SCREW RD HD SLOT #6-32 X 1/4 SST
29 1 999512 SCREW RD HD SLOT #6-32 X 3/4 SST
30 1 C00174 LOCKING NUT, 1/2 NPT, NYLON
