Burford 2000 - Bag Switch Assembly; Needle Assembly

5 6
FOLD OUT TO VIEW DRAWING
Bag Switch Assembly
*210164 Rev B RH
*210163 Rev B LH
ITEM # QTY. PART# DESCRIPTION
1 1 115162 RETAINING RING, INT 3/4
2 LH 1 302203 TRIGGER ARM REWORKED L.H.
2 RH 1 302196 TRIGGER ARM REWORKED R.H.
3 1 302460 BUSHING MACH 1/4 X 1/2 X .060
4 RH 1 610216 SPRING, TORSION, .25 ID, .038 WIRE RH
4 LH 1 610215 SPRING, TORSION, .25 ID, .038 WIRE LH
5 1 710305 HOUSING, BEARING SWITCH
6 1 710310 SHAFT, LIMIT SWITCH
7 1 710312 STOP, LIMIT SWITCH
8 1 C00111 BEARING, .75 OD X .25 ID X .28 W
9 2 955409 NUT HEX JAM 1/4-20 UNC SST
10 1 978316 SCREW SOC HD CAP 1/4-20 X 1 SST
11 1 958608 PIN ROLL, 1/8 DIA X 1/2 SST
12 1 955408 NUT JAM 1/4-28 UNF SST
13 1 979512 SCREW SOC HD CAP #8-32 UNC X 3/4 SST
Needle Assembly
302204 Rev F RH
302205 Rev F LH
ITEM # QTY. PART# DESCRIPTION
1 1 152124 ROLLER, NYLON
2 2 152125 BUSH, SST, .166 ID X 1/4 OD X 1/4 L
3 1 302060 NEEDLE MACHINE
4 1 302065 RIBBON ROLLER
5 1 978216 SCREW SOC HD CAP 1/4-28 X 1 SST
6 2 986908 SCREW BUTT HD SOC #8-32 X 1/2 SST
*Only necessary where Sealers are used
