Troubleshooting 149
Flow Chart 0-34 Excessive Belt Fuse Failure
Excessive Belt Motor fuse failures on AUX board
SAFETY WARNING:
The following troubleshooting procedure may require that tests be made with the electrical enclosures
open and power turned “ON”. These tests should only be conducted by authorized personnel who are
aware of the electrical and mechanical hazards present.
Excessive belt
tension.
Foreign material
jammed in tyer.
Check tension of all three belts driven by belt
motor. Correct as necessary. See Section
5.7 for proper adjustment.
Clear foreign material.
Improper fuses
on AUX board.
Replace with 5Amp slow blow (delay) fuses.
To Next Page
