Install Kit
15 16
FOLD OUT TO VIEW DRAWING
211141-30 Rev C LH
ITEM # QTY. PART # DESCRIPTION
1 1 302191 LOCATION POST
2 1 302327 ANGLE, TRACK
3 1 302360 A/W, STAND, ELEC. ENCLOSURE
4 1 302396 RETAINER ROD - PRODUCT SHELF
5 1 302437 A/W, BRUSH MOUNT COLLAR
6 1 302458 CONDUIT ASSY 8’
7 1 302528 A/W, TYER SUPPORT, RH
8 1 716186 TEMPLATE DRILL SERVO MARK 75
9 2 716187 ROD, PROD. SHELF 2000 W TAPER BRUSH
10 1 716190 A/W, 2000 TAPERED BRUSH MOUNT
11 REF 716191 A/W, MOUNT - TYER PIVOT T-BRUSH
12 6 955619 NUT HEX NYLOC 5/16-18 UNC SST
13 1 955939 WASHER, LOCK 5/16” SST
14 1 955976 WASHER FLAT 5/16 SST
15 2 982908 SCREW FLT HD SOC #8-32 X 1/2 SST
16 1 989712 SCREW FIN HEX 5/16-18 X 3/4 SST
17 2 989716 SCREW FIN HEX 5/16-18 X 1 SST
18 4 989724 SCREW FIN HEX 5/16-18 X 1 1/2 SST
19 1 C01286 CABLE ASSY PC TO 2000/2100
20 4 C03845 SPACER. .34 ID, .75 OD .75 L, SST
ITEM # QTY. PART # DESCRIPTION
1 1 302191 LOCATION POST
2 1 302327 ANGLE, TRACK
3 1 302360 A/W, STAND, ELEC. ENCLOSURE
4 1 302396 RETAINER ROD - PRODUCT SHELF
5 1 302437 A/W, BRUSH MOUNT COLLAR
6 1 302458 CONDUIT ASSY 8’
7 1 302529 A/W, TYER SUPPORT, LH
8 1 716186 TEMPLATE DRILL SERVO MARK 75
9 2 716187 ROD, PROD. SHELF 2000 W TAPER BRUSH
10 1 716190 A/W, 2000 TAPERED BRUSH MOUNT
11 REF 716191 A/W, MOUNT - TYER PIVOT T-BRUSH
12 6 955619 NUT HEX NYLOC 5/16-18 UNC SST
13 1 955939 WASHER, LOCK 5/16” SST
14 1 955976 WASHER FLAT 5/16 SST
15 2 982908 SCREW FLT HD SOC #8-32 X 1/2 SST
16 1 989712 SCREW FIN HEX 5/16-18 X 3/4 SST
17 2 989716 SCREW FIN HEX 5/16-18 X 1 SST
18 4 989724 SCREW FIN HEX 5/16-18 X 1 1/2 SST
19 1 C01286 CABLE ASSY PC TO 2000/2100
20 4 C03845 SPACER. .34 ID, .75 OD .75 L, SST
211140-30 Rev C RH
