Burford 2000 - Tapered Brush Assembly; Regulator Mounting Bracket Kit

Tapered Brush Assembly
210999-001 Rev H LH
210999-002 Rev H RH
11 12
FOLD OUT TO VIEW DRAWING
ITEM # QTY. PART# DESCRIPTION
1 1 111177 DECAL,110/115/120 VOLTS,1 PHASE
2 1 114804 CIRCUIT BREAKER,250V,4AMP,PUSH-IN
3 LH 1 210999-007 ASSY,TAPERED BRUSH LH
3 RH 1 210999-008 ASSY,TAPERED BRUSH RH
4 REF 211173 KIT, REGULATOR MGT BRKT
5 2 302463 CONNECTOR,RING TERM,#10,14-18GA
6 1 610160 FEMALE DISCONNECT, NYLON FULLY INSULATED
7 4 610193 FEMALE DISCONNECT, 90DEG. NYLON FULLY INSULATED
8 2.3” 610360 TERMINAL, DIN RAIL, MINI
9 7 610361 TERMINAL, BLOCK, MINI
10 1 610362 TERMINAL,END COVER,MINI
11 2 610363 TERMINAL,ANCHOR,END CLAMP,MINI
12 1 610532 JUMPER, TERMINAL, 2 POS, MINI
13 1 610533 JUMPER, TERMINAL, 3 POS, MINI
14 1 610534 TERMINAL,GROUNDING,MINI
15 2 610953 CONNECTOR, CORD, .20-.35, DOME, NYLON
16 2 610955 CONNECTOR,SEAL RING,1/2NPT,POLYETH
17 2 611158 MOTOR, 60W, 110V, 60Hz, 1450 RPM
18 1 611841 CABLE,POWERFAST,BULKHEAD,14-4,600V,15A
19 1 611842 CABLE,POWERFAST,14-4,600V,15A,5M,90°
20 2 611929 5MM HTD, 100 TEETH, 9MM WIDE SINGLE SIDED
21 2 715727 REWORK, 26T PULLEY, 12MM BORE
22 RH 1 715772 ANGLE, BAG TAIL SHELF TAPERED RH
22 LH 1 715773 ANGLE, BAG TAIL SHELF TAPERED LH
23 8 955940 WASHER LOCK 1/4” SST
24 2 955942 WASHER LOCK #8 SST
25 2 955979 WASHER FLAT #8 SST
26 4 971308 SCREW SET SOC 1/4-28 UNF X 1/2 SST
27 8 978312 SCREW SOC HD CAP 1/4-20 X 3/4 SST
28 2 979510 SCREW SOC HD CAP #8-32 UNC X 5/8 SST
29 2 987506 SCREW BUTT HD SOC #6-32 X 3/8 SST
30 2 REF. C01294-002 CAPACITOR, 18uF, 250WVAC
31 1 C07287 FEMALE DISCON., NYL. FULLY INSUL. WIRE RANGE 16-14
Regulator Mounting Bracket Kit
211173 Rev B
ITEM # QTY. PART# DESCRIPTION
1 1 112201 VALVE, AIR REGULATOR, 1/4NPT
2 1 118873 GAUGE,0-60 PSI,1/4 NPT,BACK MT,BRS
3 1 610309 LOC-LINE 1/4” ASSY
4 1 716406 BRKT, REGULATOR MNT.
5 2 955940 WASHER LOCK 1/4” SST
6 2 989910 SCREW FIN HEX 1/4-20 X 5/8 SST
