Belt Drive Assembly
302000-2 Rev N RH
302001-2 Rev L LH
3 4
ITEM # QTY. PART# DESCRIPTION
1 2 103519 SPRING EXTENSION
2 1 103972 SENSOR,MICRO SWITCH
3 1 111174 DECAL, KEEP THIS GUARD IN PLACE
4 1 115290 SPRING, COMPRESSION
5* RH REF. 210164 ASSY, BAG SWITCH RH
5* LH REF. 210163 ASSY, BAG SWITCH LH
6 2 302019 PULLEY, BELT DRIVE
7 1 302020 BELT, 28.5” RED 3/8 P
8 1 302029 RIBBON BLOCK
9 RH 1 302034 ASSY, BEARING HOUSING TWIST HOOK RH
9 LH 1 302035 ASSY, BEARING HOUSING TWIST HOOK LH
10 RH 1 302036 HOLDER / SHEAR MOUNT, R.H.
10 LH 1 302037 HOLDER / SHEAR MOUNT, L.H.
11 1 302045 PLATE, LOWER FRONT
12 1 302046 PLATE, TOP FRONT
13 1 302056 GUIDE, LOWER
14 1 302072 PROXIMITY MOUNT
15 RH REF. 302080 A/W, LOWER FRONT PLATE, R.H.
15 LH REF. 302081 A/W, LOWER FRONT PLATE, L.H.
16 7 302096 STANDOFF, FRONT
17 7 302106 SPACER, 1/2” DIA. X 1/4 ID X .283 L.
18 2 302110 WASHER, COVER
19 1 302111 MAGNET RECEIVER
20 RH 1 302112 HINGE, COVER PLATE, R.H.
20 LH 1 302113 HINGE, COVER PLATE, L.H.
21 RH 1 302114 HINGE, COVER PLATE, R.H.
21 LH 1 302115 HINGE, COVER PLATE, L.H.
22 RH 1 302128 A/W, TYER RIBBON RELEASE, R/H
22 LH 1 302129 A/W, TYER RIBBON RELEASE, L/H
23 1 302132 GEARBELT,3/8 PITCH,36.7 LONG
24 RH 1 302196 TRIGGER ARM REWORK R.H.
24 LH 1 302203 TRIGGER ARM REWORK L.H.
25 RH 1 302204 ASSY, NEEDLE R/H, 2000
25 LH 1 302205 ASSY, NEEDLE R/H, 2100
26 7 302206 ASSY, IDLER
27 2 302207 BUSHING ASSY GUIDE SUPPORT
28 1 302299 PLATE SERIAL,SERVO TYER
29 2 302434 BUSHING, 3/8 X 5/8 X .047 MACH.
30 2 302435 BUSHING, 3/8 X 5/8 X .062 MACH.
ITEM # QTY. PART# DESCRIPTION
31 1 302452 BAG STOP SUPPORT PLATE
32 1 302456 LEVER - BAG STOP
33 1 302457 ROD, ACTUATION BAG STOP, SERVO
34 2 302460 BUSHING MACH 1/4 X 1/2 X .060
35 1 302526 ASSY, ADVANCED HOLDER/SHEAR
36 1 302873 SPACER, BAG STOP SPRING
37 1 302874 SPRING-EXTENSION 3/8 OD 2” L .031
38 3 401351 BUSH MACH 3/8OD X 1/4ID X .031
39 REF. 401628 GUARD, SERVO LOWER A/W
40 RH REF. 710496 A/W, LOWER GUARD, TEC, RH W/SEALER
40 LH REF. 710495 A/W, LOWER GUARD, TEC, LH W/SEALER
41 2 954712 PIN DOWEL, 3/16 DIA X 3/4 SST
42 2 955615 NUT HEX ACORN 1/4-20 UNC SST
43 2 955621 NUT HEX NYLOC #10-24 UNC SST
44 5 955661 NUT HEX NYLOC 1/4-20 UNC SST
45 5 955940 WASHER LOCK 1/4” SST
46 12 955941 WASHER LOCK #10 SST
47 3 955977 WASHER FLAT 1/4” SST
48 9 955978 WASHER FLAT #10 SST
49 4 974906 SCREW SHLDR 1/4 X 3/8, #10-24 SST
50 2 975012 SCREW SHLDR 5/16 X 3/4, 1/4-20 SST
51 2 978324 SCREW SOC HD CAP 1/4-20 X 1 1/2 SST
52 2 978332 SCREW SOC HD CAP 1/4-20 X 2 SST
53 4 978906 SCREW SOC HD CAP #10-24 X 3/8 SST
54 2 978912 SCREW SOC HD CAP #10-24 UNC X 3/4
55 2 982312 SCREW FLT HD SOC #10-24 X 3/4 SST
56 1 985716 SCREW BUTT HD SOC 1/4-20 X 1 SST
57 1 985722 SCREW BUTT HD SOC 1/4-20 X 1 3/8 SST
58 6 985724 SCREW BUTT HD SOC 1/4-20 X 1 1/2 SST
59 1 986304 SCREW BUTT HD SOC #10-24 X 1/4 SST
60 1 986308 SCREW BUTT HD SOC #10-24 X 1/2 SST
61 5 986312 SCREW BUTT HD SOC #10-24 X 3/4 SST
62 1 986316 SCREW BUTT HD SOC #10-24 X 1 SST
63 2 987504 SCREW BUTT HD SOC #6-32 X 1/4 SST
64 2 989916 SCREW FIN HEX 1/4-20 X 1 SST
65 1 989928 SCREW FIN HEX 1/4-20 X 1 3/4 SST
66 REF. C07625 SNSR,PROX,8MM,10-30VDC, NPN, NO
67 REF. C07626 SENSOR,CABLE,M8,3WIRE,F,QC,90
*Only necessary where Sealers are used
