Auxiliary functions
Position set-
point value
Control
difference
Xd1
Position
actual value
to the
controller
Xd1‘
Dead zone
Xd1
Xd1‘
Figure 68: Graph - X.CONTROL
26.2.9. P.CONTROL – Setting up and parameterization of the
process controller
Parameterization of the process controller is described in Chapter “25.1. P.CONTROL – Setting up and param-
eterization of the process controller”
