Description of System
10.5. Type label
Explanation of the device-specific specifications on the type label:
Example:
Type
Operating voltage
Nominal power
Device variant
(NAMUR/Remote, 24 V DC/
PROFIBUS DP)
Supply pressure, Degree of
protection
Ambient temperature
CE marking
Approval mark CSA (for Canada
and USA)
Manufacture code
8792 24V DC 5W
NAMUR Profibus DP
P=1.4…7bar IP65/67
Tamb -10..+60°C
S/N 123456
00999999 W17MA
Made in Germany
Serial number
Order number
Barcode (contains order
number and serial number)
Figure 8: Example of type label
10.6. Mechanical data
Dimensions See data sheet
Material
Housing material Plastic-coated aluminium
Other external parts Stainless steel (V4A), PC, PE, POM, PTFE
Sealing material EPDM, NBR, FKM
Mass approx. 1.0 kg
