DeviceNet
32.1. Connection diagram Type 8792
X3 - M12, 5-pole
circular connector
2
3
4
1
5
X4 - M8, 4-pole socket,
optional (for remote
model only)
Function
earth FE
4
2
1
3
X1 - M12, 8-pole
circular connector
3
4
12
5
6
7
8
Figure 124: Connection Device-Net, positioner Type 8792
32.2. Connection diagram Type 8793
X5 - M8, 4-pole circular
connector
24
3
1
X3 - M12, 5-pole
circular connector
2
3
4
1
5
X4 - M8, 4-pole socket,
optional (for remote model
only)
Function
earth FE
42
1
3
X1 - M12, 8-pole
circular connector
3
4
1
2
5
6
7
8
Figure 125: Connection DeviceNet, process controller Type 8793
The device is supplied by the operating voltage, galvanically isolated from the DeviceNet, not by the V+ and
V- voltage of the DeviceNet.
