Burkert 8792 - Interfaces; Safety.settings.if.the.bus.fails

203
DeviceNet
Drop line length (Drop Lines)
Baud rate
Length of the drop lines
Maximum length
Maximum total length Drop lines
in the network
125 kbaud
6 m for all baud rates
156 m
250 kbaud 78 m
500 kbaud 39 m
Table 112: DeviceNet; drop line length
31.3. Interfaces
Input for process
actual value*
4 – 20 mA
frequency
Pt 100
Binary input
24 V DC
Type 8792/8793
DeviceNet
2 binary outputs
24 V PNP
Initiator 1 / Initiator 2
24 V PNP NO
Inputs Outputs
Supply
Operation
Note:
Optional inputs and outputs are illustrated by dotted lines
Bus
Bus
* only for process controller Type 8793
Figure 123: DeviceNet interfaces
31.4. Safety settings if the bus fails
The position is approached which corresponds to the set-point value last transferred (default setting).
Other setting options (see chapter “33.3. BUS.COMM – Settings on Type 8792/8793”).
