DeviceNet
33.5.3. Offline parameterization of the Device
When a device has been inserted into the DeviceNet configuration of RSNetWorx, the device can be parameterized
offline.
“Figure 129” indicates how, for example, an input assembly which deviates from the factory setting (input process
data can be transferred via I/O connection) can be selected.
However, ensure that the length of the process data during a subsequent configuration of the DeviceNet master/
scanner is adjusted accordingly (see chapter entitled “33.6. Configuration example 2”).
All parameter changes implemented offline must become operative for the real device at a later date by a
download process.
Figure 129: Screenshot - DeviceNet - Offline Parameterization, Select input assembly
