14
Description of System
5.1.3. Overview of the mounting options
Mounting NAMUR on
rotary actuator
Mounting NAMUR
with mounting bracket
on a linear actuator
Remote mounting
with mounting bracket
Remote mounting
with DIN rail
Table 1: Overview of the mounting options
english
Types 8792, 8793
