Installation
Type 8792, 8793
english
12.2. Attachment to a continuous valve with linear
actuators according to NAMUR
The valve position is transferred to the position sensor installed in the positioner via a lever (according to
NAMUR).
12.2.1. Attachment kit for linear actuators (serial no. 787 215)
(Can be purchased as an accessory from Bürkert).
Part no. Quantity Name
1 1 NAMUR mounting bracket IEC 534
2 1 Hoop
3 2 Clamping piece
4 1 Driver pin
5 1 Conical roller
6a 1 NAMUR lever for stroke range 3 – 35 mm
6b 1 NAMUR lever for stroke range 35 – 130 mm
7 2 U-bolt
8 4 Hexagon bolt DIN 933 M8 x 20
9 2 Hexagon bolt DIN 933 M8 x 16
10 6 Circlip DIN 127 A8
11 6 Washer DIN 125 B8.4
12 2 Washer DIN 125 B6.4
13 1 Spring VD-115E 0.70 x 11.3 x 32.7 x 3.5
14 1 Spring washer DIN 137 A6
15 1 Locking washer DIN 6799 - 3.2
16 3 Circlip DIN 127 A6
17 3 Hexagon bolt DIN 933 M6 x 25
18 1 Hexagon nut DIN 934 M6
19 1 Square nut DIN 557 M6
21 4 Hexagon nut DIN 934 M8
22 1 Guide washer 6.2 x 9.9 x 15 x 3.5
Table 11: Attachment kit for linear actuators
