DeviceNet
31. DESCRIPTION
31.1. Explanation of term DeviceNet
DeviceNet
• The DeviceNet is a field bus system which is based on the CAN protocol (Controller Area Network). It enables
actuators and sensors (slaves) to be networked with higher-level controllers (master).
• The Type 8792/8793 in the DeviceNet is a slave device according to the Predefined Master/Slave Connection
Set stipulated in the DeviceNet specification. Polled I/O, Bit Strobed I/O and Change of State (COS) are sup-
ported as an I/O connection variant.
• With DeviceNet it is necessary to differentiate between cyclical or event-driven high-priority process messages
(I/O Messages) and acyclical low-priority management messages (Explicit Messages).
• The protocol process conforms to the DeviceNet specification Release 2.0.
31.2. Technical data
EDS file BUER8792.EDS
Icons BUER8792.ICO
Baud rate 125 kbit/s, 250 kbit/s, 500 kbit/s
(can be adjusted by pressing operator keys on the device or via network);
Factory setting 125 kBit/s
Address
0 – 63;
(can be adjusted by pressing operator keys on the device or via network);
Factory setting 63
Process data
7 static input assemblies
(Input: from the Type 8792/8793 to the DeviceNet-Master/Scanner)
4 static output assemblies
Total line length according to DeviceNet specification
(Total line length = total of all trunk and drop lines)
Baud rate
Maximum total line length
Thick cable Thin cable
125 kbaud 500 m
100 m for all baud rates
250 kbaud 250 m
500 kbaud 100 m
Table 111: DeviceNet; total line length
