12.3. Attachment to a continuous valve with rotary
actuator
The shaft of the position sensor integrated in the positioner is connected directly to the shaft of the rotary
actuator.
12.3.1. Mounting kit (VDI/VDE 3845) on rotary actuator
(part no. 787338)
(Can be purchased as an accessory from Bürkert).
Part no. Quantity Name
1 1 Adapter
2 2 Setscrew DIN 913 M4 x 10
3 4 Cheese-head screw DIN 933 M6 x 12
4 4 Circlip B6
5 2 Hexagon nut DIN985, M4
Table 12: Mounting kit on rotary actuator
Other accessories:
The order number for the assembly bridge with fastening screws (according to VDI/VDE 3845) can be found on
the data sheet for Type 8792/8793.
12.3.2. Installation
WARNING!
Risk of injury from improper installation.
▶ Installation may be carried out by authorised technicians only and with the appropriate tools.
Risk of injury from unintentional activation of the system and an uncontrolled restart.
▶ Secure system from unintentional activation.
▶ Following assembly, ensure a controlled restart.
Procedure:
→ Specify the attachment position of the Type 8792/8793:
- parallel to the actuator or
- rotated by 90° to the actuator.
→ Determine home position and direction of rotation of the actuator.
→ Connect adapter to the shaft of the Type 8792/8793 and secure with 2 setscrews.
