Burkert 8792 - Connection.diagram.type.8792; Connection.diagram.type.8793

188
PROFIBUS DP
29.1. Connection diagram Type 8792
X3 - M12, 5-pole
circular connector *
1
4
3
2
5
X2 - M12, 5-pole socket *
2
3
4
1
5
X4 - M8, 4-pole socket,
optional (for remote model
only)
Functional
earth FE
42
1
3
X1 - M12, 8-pole
circular connector
3
4
12
5
6
7
8
* (inversely coded,
PROFIBUS DP)
Figure 116: Connection PROFIBUS DP, positioner Typ 8792
29.2. Connection diagram Type 8793
X5 - M8, 4-pole
circular connector
24
3
1
X3 - M12, 5-pole
circular connector *
1
4
3
2
5
X2 - M12, 5-pole
socket *
2
3
4
1
5
X4 - M8, 4-pole socket,
optional (for remote
model only)
Functional
earth FE
42
1
3
X1 - M12, 8-pole
circular connector
3
4
12
5
6
7
8
* (inversely coded,
PROFIBUS DP)
Figure 117: Connection PROFIBUS DP, process controller Typ 8793
english
Type 8792, 8793
