Type of image
Select the object for which to change the setting. <Text> represents letters and characters, <Graphics>
represents lines and gures, and <Image> represents photos and images.
<Resolution>
Produces a ne print with clear edges of text. It is suitable for printing characters and ne lines.
<Color Tone>
Produces a sharp print with strong contrast of lightness and darkness. It is suitable for printing image data
such as photo image data.
<Gradation>
Produces a print with smooth gradation or smooth edges. It is suitable for printing gures or graphs
containing gradation areas.
<High Resolution>
As compared to <Resolution>, this produces a ner print but quality stability is slightly lower. It is suitable to
obtain a print of character data or ne line data or CAD data with sharp edges.
BarDIMM
*2
This setting enables you to print bar codes supported by the Barcode Printing Kit. If <Enable> is selected, the
machine will generate bar codes when it receives bar code commands from the host computer. If <Disable> is
selected, bar codes will not be generated, even if bar code commands are sent from the host computer.
Enable
Disable
<Menu>
<Printer Settings>
<PCL>
<BarDIMM>
Select <Enable> or <Disable>
● To enable the BarDIMM menu, it is necessary to activate the Barcode Printing Kit. When you are not
printing bar codes, make sure to disable the BarDIMM menu. Otherwise, the processing speed of
regular print jobs may be reduced.
● The default setting is <Disable>. If you activate the Barcode Printing Kit, it changes to <Enable>.
FreeScape
Specify the AEC (Alternate Escape Code) to be used for bar code commands when the host computer does not
support the standard Escape Code.
Off
Setting Menu List
692
