Stacking Printed Materials with ARCH D Landscape, ARCH C
Landscape, A1 Landscape or A2 Landscape (Position 4)
• Supported paper size•
◦ 24"x36" (ARCH D) 24.00 x 36.00 inches (609.6 x 914.4 mm)
◦ 18"x24" (ARCH C) 18.00 x 24.00 inches (457.2 x 609.6 mm)
◦ A1 23.39 x 33.11 inches (594.0 x 841.0 mm)
◦ A2 16.54 x 23.39 inches (420.0 x 594.0 mm)
Pull down the rod (fixed) (C) toward you. Set the rod (adjustable) in the groove (B) at the upper of the
stand, and then set the flapper (A) horizontally so that the stacker configuration is the Position 4.
181
