6.
Align the angle adjustment lever with the red square and close the top cover.
6.
A test pattern is printed for adjustment.
Important
• Do not touch the linear scale (A), carriage shaft (B), or ink tube stabilizer (C). Touching these may•
cause malfunction.
421
