Approx. 54.8 x 48.2 x 46 in. (1390 x 1222 x 1168 mm)
Printer and Stand (when using basket: basket position 3) *1:
Approx. 54.8 x 56.5 x 46 in. (1390 x 1434 x 1168 mm)
Printer and Stacker (Stacker position closed) *2:
Approx. 54.8 x 44.2 x 46 in. (1390 x 1122 x 1168 mm)
Printer and Stacker (Stacker position open) *2:
Approx. 54.8 x 46.8 x 46 in. (1390 x 1188 x 1168 mm)
*1 For details on the Basket Position, see Example Basket Configurations.
*2 For details on the Stacker Position, see Example Stacker Configurations.
Stand may not be provided depending on the region where the printer is
purchased.
Weight Printer only (without print head and ink tanks):
Approx. 191 lb (87 kg)
Stand and basket: Approx. 40 lb (18 kg)
Roll unit: Approx. 42 lb (19 kg)
Stacker: Approx. 31 lb (14 kg)
Space for installation (W x D x
H)
Printer and Stand (without basket):
Approx. 70.5 x 57.8 x 61.5 in. (1790 x 1466 x 1560 mm)
Printer and Stand (when using basket) *1:
Approx. 70.5 x 66.3 x 61.5 in. (1790 x 1684 x 1560 mm)
Printer and Stacker *2:
Approx. 70.5 x 74.4 x 61.5 in. (1790 x 1888 x 1560 mm)
*1 For details on the Basket Position, see Example Basket Configurations.
*2 For details on the Stacker Position, see Example Stacker Configurations.
TX-2100 / TX-5210
Power supply 100-240 V AC (50/60 Hz)
Power consumption When printing: 87 W max. *1
In Sleep mode: 2.0 W max. *1
When power is off: 0.3 W max. *2
*1 Wired LAN connection
*2 The printer uses a trace amount of power even when turned off. To stop all
power consumption, turn off the printer and unplug the power cord.
Operating environment Temperature: 59 to 86 °F (15 to 30 °C)
Humidity: 10 to 80 % RH (with no condensation)
Dimensions (W x D x H) Printer only:
Approx. 43.8 x 28.9 x 24.8 in. (1110 x 734 x 629 mm)
Printer and Stand (when basket is not used):
524
