Approx. 43.8 x 30.2 x 46 in. (1110 x 766 x 1168 mm)
Printer and Stand (when using basket: basket position 1) *1:
Approx. 43.8 x 38.8 x 46 in. (1110 x 984 x 1168 mm)
Printer and Stand (when using basket: basket position 2/4/5) *1:
Approx. 43.8 x 48.2 x 46 in. (1110 x 1222 x 1168 mm)
Printer and Stand (when using basket: basket position 3) *1:
Approx. 43.8 x 56.5 x 46 in. (1110 x 1434 x 1168 mm)
Printer and Stacker (Stacker position closed) *2:
Approx. 43.8 x 44.2 x 46 in. (1110 x 1122 x 1168 mm)
Printer and Stacker (Stacker position open) *2:
Approx. 43.8 x 46.8 x 46 in. (1110 x 1188 x 1168 mm)
*1 For details on the Basket Position, see Example Basket Configurations.
*2 For details on the Stacker Position, see Example Stacker Configurations.
Stand may not be provided depending on the region where the printer is
purchased.
Weight Printer only (without print head and ink tanks):
Approx. 163 lb (74 kg)
Stand and basket: Approx. 37 lb (17 kg)
Roll unit: Approx. 35 lb (16 kg)
Stacker: Approx. 26 lb (12 kg)
Space for installation (W x D x
H)
Printer only:
Approx. 59.5 x 56.5 x 40.2 in. (1510 x 1434 x1020 mm)
Printer and Stand (without basket):
Approx. 59.5 x 57.8 x 61.5 in. (1510 x 1466 x 1560 mm)
Printer and Stand (when using basket) *1:
Approx. 59.5 x 66.3 x 61.5 in. (1510 x 1684 x 1560 mm)
Printer and Stacker *2:
Approx. 59.5 x 74.4 x 61.5 in. (1510 x 1888 x 1560 mm)
*1 For details on the Basket Position, see Example Basket Configurations.
*2 For details on the Stacker Position, see Example Stacker Configurations.
Printing performance
Print method Bubblejet
Maximum resolution 2400 dpi (horizontally) * x 1200 dpi (vertically)
* Prints with a minimum 1/2400 inch dot pitch between ink droplets.
Print head PF-06
Number of nozzles MBK: 5120 nozzles, others: each 2560 nozzles
525
