CAPINTEC, INC. CAPRAC
®
-t
11-24 REPORTS April 2021
To inactivate the selected Chi Square Test, touch the INACTIVATE button. Figure
11-10 Inactivate Record Screen will appear.
To enter an optional comment (description or reason) for the selected Chi Square
Test result inactivation, touch the Comment: field box. Figure 11-11 Alphanumeric
Keypad Screen will appear.
Input the desired comment (description or reason) for the invalidation and touch the
ACCEPT button. Figure 11-10 Inactivate Record Screen will re-appear with the
Comment: field box populated with the entered comment. The comment can contain
any combination of 22 alphanumeric characters maximum.
To cancel any changes and return to Figure 11-10 Inactivate Record Screen, touch
the CANCEL button.
To complete the inactivation of the selected Chi Square Test result, touch the YES
button.
If it is decided not to inactivate the selected Chi Square Test result, touch the NO
button.
View Chi Square Test Spectrum
To view the spectrum of a specific counting repetition, touch any of the blue
highlighted Counts field boxes. The Spectrum Screen (similar to
Figure 11-12
System Test Spectrum Screen) will appear.
A Region of Interest may be defined using the BLUE and GREEN ARROW buttons to
place vertical line cursors around the ROI. DOUBLE ARROW buttons move the
cursor approximately 75 energy channels. SINGLE ARROW buttons move the cursor
approximately 7.5 energy channels.
Note: The actual energy channel keV will vary depending upon the Auto Calibration.
When the vertical cursor is moved, the channel energy (keV) and the number of
counts in that energy channel are displayed. Once the vertical cursors are set, the
total counts in the ROI are displayed.
To print the spectrum, touch the PRINT button.
To return to Figure 11-18 Chi Square Test Result Screen, touch the BACK button.
Exit Detailed Result
To exit Figure 11-18 Chi Square Test Result Screen, touch the BACK button. Figure
11-16 Chi Square Tests Search Screen will re-appear.
