Cisco 7925G Administration Guide

Install CU File
The CU file is provided by Cisco in the .ava file format.
Install the CU on the Wavelink Avalanche Management Console.Note
For more information, see the Wavelink Avalanche Management Console documentation.
To install the phone CU, follow these steps.
Procedure
Step 1
Launch the Wavelink Avalanche Management Console and connect to the agent.
Step 2
Choose Software Management > Install Software Package.
Step 3
Browse to the location of the .ava file containing the CU and select it.
Step 4
Click New and enter the software collection name under which the phone configuration files will be added.
Step 5
Follow the instructions on the wizard to complete the installation.
Step 6
When the installation completes, expand the software collection name on the left pane. The phone CU file
name 7925CU appears with a red “x” (disabled) next to it.
Step 7
Right-click 7925CU and choose Enable Package.
The installation is complete. The following additional steps are optional. They configure the selection
criteria so you can easily apply changes to a device group.
Note
Step 8
Right-click the software collection (containing the phone CU) and choose Settings.
Step 9
Click the button at right of the Selection Criteria box to launch the Selection Criteria wizard.
Step 10
Select an item from the Source Properties list on the left, and enter a value in the Selection Expression text
box.
Step 11
Repeat the previous step for each property and value you wish to include. When finished, click Compile, and
then click Test Expression.
Step 12
Review the list displayed under Matching Clients to ensure the selection criteria have been met.
Step 13
Click Apply, then click OK.
Update Configuration Files
You can update a phone configuration file using the CU installed on a Wavelink Avalanche Management
Console.
The following table lists the configuration file settings.
Cisco Unified Wireless IP Phone 7925G, 7925G-EX, and 7926G Administration Guide
137
Wavelink Avalanche Server
Install CU File

Cisco 7925G Specifications

General

Keypad number of keys	12
Display diagonal	2 \
Display resolution	176 x 220 pixels
Call waiting	Yes
Lines quantity	6 lines
Voice codecs	G.711a, G.722, G.729a, iLBC
Security algorithms	128-bit WEP, SSL/TLS, WPA
Supported network protocols	DHCP, TFTP, DNS, SCCP, SRST
Input voltage	100 - 240 V
Dimensions (WxDxH)	52 x 20 x 127 mm
Minimum system requirements	Cisco Unified Communications Manager 4.1, 4.2, 4.3, 5.1, 6.0, 6.1, 7.0 + Cisco Unified Communications Manager Express 4.3 +
Input frequency	50/60 Hz
Storage temperature (T-T)	-30 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Product type	IP Phone
Product color	Gray
Safety	UL 60950, CSA 22.2 No.60950, EN 60950, IEC 60950, AS/NZS 60950, IEC 60529 (IP 54)
Certification	47 CFR 15 B ICES-003 B EN 55022 B AS/NZS CISPR 22 B CISPR 22 B VCCI B EN 61000-3-2 EN 61000-3-3 KN 22 EN 55024 EN 50082-1 EN 61000-6-1 EN 300386 EN 60601-1-2 KN
Compliance industry standards	IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.1X, IEEE 802.11e

Weight and Dimensions

Weight	138 g
