DescriptionItem
Number data packets received - VideoDataRcvVI
Number data packets received - VoiceDataRcvVO
Call Statistics
You can access the Call Statistics screen on the phone to display counters, statistics, and voice quality metrics
in these ways:
During the call
You can view the call information by pressing the Select button twice rapidly.
After the call
You can view the call information captured during the last call by displaying the Call Statistics screen.
You can remotely view the call statistics information using a web browser to access the Streaming Statistics
web page. For more information about remote monitoring, see Remote Monitoring, on page 195
Note
A single call can have multiple voice streams, but data is captured for only the last voice stream. A voice
stream is a packet stream between two endpoints. If one endpoint is put on hold, the voice stream stops even
though the call is still connected. When the call resumes, a new voice packet stream begins, and the new call
data overwrites the former call data.
Related Topics
View Status Messages Screen, on page 186
View Network Statistics, on page 189
Firmware Versions, on page 193
View Call Statistics Screen
To display the Call Statistics screen for information about the last voice stream, follow these steps:
Procedure
Step 1
Press SETTINGS > Status.
Step 2
Scroll to and select Call Statistics. The list of statistics appears.
Step 3
Use the Navigation button to scroll through the items on the Call Statistics screen.
Call Statistics Fields, on page 192 describes the items that appear on this screen.
Step 4
To exit the Call Statistics screen, press Back.
Cisco Unified Wireless IP Phone 7925G, 7925G-EX, and 7926G Administration Guide
191
Security, Device, Model, Status, and Call Statistics Information
Call Statistics
