Setting up the baler
Disengaging the drive of the net wrapping
mechanism
ROLLANT 240/250/254/255 with standard controls:
Push the double gear (Z) on the left side of the
machine outwards and secure it with the spring clip
(S).
(Fig. 30)
Setting the number of twine wraps
ROLLANT 240/250/254/255 with standard controls:
You can change the number of wrappings by moving
the V-belt (K) on the V-belt pulley of the shaft (A and
B) and V-belt (R) onto the V-belt pulley of the shaft (B
and C).
Note!
The V-belt brake (D) must be off during "twine
wrapping" operation.
(Fig. 31, 32)
30
A
B
K
R
D
C
31
