000 299 119 5 - BA ROLLANT 240 - 250 - 254 - 255 14.4.5
Maintenance
Setting the stop on the grease pump
Note!
When setting the stop on the grease pump,
make sure that the tailgate is closed.
– Tighten up screw (D) so that the cap nut (E) is
adequately positioned on the ram (K), so that the
distance (X) between the ram (K) and its support
(J) is from 1 to 2 mm (0.04 to 0.08 inch).
– To lock the position, tighten up the hexagonal nut
against the stop (G).
(Fig. 12)
Filling the grease container
– Open the left-hand side flap.
– Connect a manual or automatic grease pump (T)
to the output (M) on the grease pump.
– Fill the pot by pressing on the manual or automatic
grease pump.
– Close the left-hand side flap.
(Fig. 13, 14)
X
K
J
E
D
G
12
T
M
13
M
14
