7.4.2 BA ROLLANT 240 - 250 - 254 - 255 - 000 299 119 5
Prior to operation
Hydraulic system of CLAAS Control Terminal
models
Connect the oil pressure line (thinner) to a
single-acting control valve.
Connect the return flow tube without pressure (thicker)
to the quick-release coupling of the tractor’s hydraulic
oil tank.
Required connector size: 3/4” (see “Specifications”).
Note!
When the hydraulic oil tank fitting is too small,
the tractor must be re-equipped.
Note!
The maximum rate of flow for the hydraulic oil in
the high convenience version of the baler is
80 l/min (21 us gal/min). If the rate of flow is
higher, the hydraulic oil may heat up. If this
occurs, the rate of flow must be adjusted (see
tractor operating instructions).
The hydraulic pressure can be set at the
pressure control valve from between 70 (1015
psi) and a maximum of 150 bar (2175 psi).
