14.6.2 BA ROLLANT 240 - 250 - 254 - 255 - 000 299 119 5
Maintenance
Pull out the filter insert (E) from the upper section of
the housing (D).
Clean the upper and lower sections of the housing.
Change the damaged O-Ring (F) or supporting ring
(G).
Note!
First insert the O-Ring and then the supporting
ring into the groove (H) on the upper section of
the housing.
Screw in the bottom section of the housing firmly.
Only use original filters!
(Fig.1,2,3,4)
Bleed valve combination with pressure limiting
valve
Attention!
Repairs of the hydraulic system should only
be carried out by CLAAS repair and service
centers.
After changing the hydraulic oil filter or after other
maintenance or repairs to the hydraulic system, the
valve combination should be bled. Air shut in the
hydraulic system can have a negative effect on the
baling pressure.
