14.3.8 BA ROLLANT 240 - 250 - 254 - 255 - 000 299 119 5
Maintenance
Adjusting the twine tightener
Adjust the spring length (X) so that it is 95 mm
(3.74 inch) long in its resting position (twine guide
tubes are perpendicular to the machine).
(Fig. 23)
Adjusting the twine knife control
When the twine knives are in their resting position and
the link plates (L) in the knife holders are in contact
with the twine guides (F) at the same time, the wire
ropes (S) must be slightly taut.
Note!
The High Convenience version is adjusted in the
same way.
Adjust the angle lever (W).
(Fig.24,25,26)
28296
X
7
6
23
24
F
L
S
25
26
