000 299 119 5 - BA ROLLANT 240 - 250 - 254 - 255 12.1.3
Faults and remedies
Netting breaks at the start of wrapping. 1. Tension too high on net tightener. Loosen the
net tightener or refeed the netting through only
one guide (brake) roller arrangement.
2. The net brake bracket is dirty and needs
cleaning.
3. The V-belt brake is not engaged - engage it.
4. Flow spoiler corroded.
5. Loosen net braking bow
(with front left spring adjustment)
6. Limit flow spoiler movement with stop (right)
7. Net trough corroded
Netting slips on the rubber-coated roller. 1. Net incorrectly installed.
2. Loosen net braking bow (with front left spring
adjustment)
3. Rubber-coated roller dirty.
4. Tension steel roller (2x)
5. Flow spoiler or net trough corroded.
Net wraps around steel roller. 1. The steel roller is dirty and needs cleaning.
Net on bale too loose. 1. Loosen net braking bow (with front left spring
adjustment).
2. Run net through two flow spoilers.
3. Adjust limiting plate for upward flow spoiler
movement (right).
Too few net wraps on bale. 1. Knife trip quadrant jammed.
2. Wrong setting.
Net is not cut. 1. Net incorrectly fitted.
2. Knife guard not removed.
3. Knife jammed or rusty.
4. Insufficient net tension.
5. Tighten the spring on front left side of baler.
6. Cutting blade not in top position.
7. Hook overtravel not wide enough, adjust.
Damage to netting on bale. 1. When loading the bale with the front loader,
only stab the loader tines into the end of the
bale. Avoid pushing the bale over the ground.
2. Check bale discharge ramp for damage.
Remedy the trouble, remove any burrs.
3. Remove possibly existing burrs from rollers.
Faults Cause or remedy
